| Serial Number | Item | Technical Parameters | Remarks |
| 1 | Nominal Voltage | 48V | |
| 2 | Rated Capacity | 45Ah | @0.3 C3A, 25℃ |
| 3 | Minimum Capacity | 43Ah | @0.3 C3A, 25℃ |
| 4 | Cell Model | CATL46217-45Ah | |
| 5 | Combination Method | 1P15S | |
| 6 | Standard Charging Current | 20A | |
| 7 | Charging Cut-off Voltage | 54.75V | Upper Limit of Single Cell Voltage: 3.65V |
| 8 | Standard Discharge Current | 20A | |
| 9 | Discharge Termination Voltage | 37.5V | Lower Limit of Individual Cell Voltage 2.5V |
| 10 | Standard Charging Time | Approximately 2 hours | |
| 11 | Continuous Discharge Current | 45A | 15℃~45℃ |
| 12 | Maximum Discharge Current | 60A | 15℃~45℃, <30S |
| 13 | Instantaneous Peak Discharge Current | 200A | 15℃~45℃ |
| 14 | Communication Method | RS485 | Matching Client Protocol |
